565 Big Block Chevy Supercharged Drag Race Engine $26,500

565 Big Block Chevy Supercharged Drag Race Engine Shown With Optional Equipment


New! 565/1200+ $26,500

Cost Effective, Simple To Run And Incredibly Consistent This New Engine Might Be Just What You've Been Looking For!!

Throw In "Cool Factor" Looks And Sound To Just Add To Your Enjoyment. If You've Never Driven A Supercharged Race Car Before You Owe It To Yourself To Feel The Instant Response And Body Piercing Sound These Babys Put Out. Perfect For Fast "Big Dollar" Bracket Racing These Bad Boys Really Shine When Compared To Naturally Aspirated Power. Time To Put Your "Big Boy" Pants On!!

Limited Availability So Get Your Order In Soon!!

  • Horsepower
  • Torque
  • Bore & Stroke
  • Compression Ratio
  • Fuel
  • Boost
  • 1200 @ 7400 RPM
  • 985 @ 5500 RPM
  • 4.600 x 4.250
  • 12.9 to 1
  • Methanol
  • 7.0 lbs


  • Dart Big "M" 9.800" Low Deck Block w/4 Bolt Splayed Caps
  • Manley 4340 Fully Counterweighted Forged Steel Crank
  • Molnar Power Adder Plus Rods w/ARP2000 Symmetrical Bolts
  • Clevite 77 H-Series Main & Rod Bearings
  • JE Forged Aluminum Blower Pistons
  • H13 Tool Steel Pins
  • Total Seal AP Steel .017" Dykes Ring Set
  • HIPPO Severe Duty Solid Roller Lifters w/Hi-Pressure Pin Oiling
  • Rollmaster Billet Timing Set w/IWIS Chain & Torrington Bearing
  • Brodix BB3X 363 Rectangle Port Heads w/CNC Chambers
  • Severe Duty 2.300" 11/32" Stainless Intake Valves
  • Severe Duty 1.880" 11/32" Stainless Exhaust Valves
  • PAC Racing 1.645" Triple Springs w/Titanium Retainers & 10° Bead Locks
  • ARP Head Stud Kit w/Parallel Ground Washers
  • T&D Shaft Rockers
  • Trend .165" Wall 7/16 Exhaust Pushrods
  • Cometic MLS (Multil Layer Steel) Head Gaskets
  • SSRE/Moroso Custom Stroker Pan w/Windage Tray
  • Moroso Race Prepped Oil Pump w/Tig-Welded HD Pickup
  • ATI Double Keyed Super Damper w/Billet Pointer
  • Polished Aluminum Valve Covers
  • The Blower Shop 250cc Roots Style Blower
  • APD 1450 CFM Alcohol Carb w/Billet Aluminum Adapter
  • APD Alcohol Pump Drive & Diverter Kit
  • Internally Balanced
  • Professionally Blueprinted, Assembled & Dyno'd
Igniton Components
MSD Electronic Ignition Package includes MSD 85705 Pro Billet Locked Distributor w/Ford HEI-Style Cap, Bronze Gear, Custom MSD/Moroso 8.5mm Wire Set. Dyno Tested and Calibrated on your engine. $595
Crank Trigger Ignition Upgrade $295
MSD 7AL-2 Electronic Ignition Box (Direct Plug-in For Our MSD Distributors) $559
MSD 8201 Pro Power Coil $122
Blocks
Dart Steel Billet Main Cap Upgrade $450
Brodix Aluminum Block w/Steel Billet Caps, Special Head Stud Kit & Additional Machining (Slightly Less Peak HP) $4000
HIP® Process (Hot Isostatic Pressing) For Increased Durability With Aluminum Blocks $500
Lifters
HIPPO Severe Duty Pressure Fed Roller Lifters w/Solid Bushed Rollers (No Needle Bearings) $295
Valvetrain
Severe Duty Inconel Exhaust Valves $350
Needle Bearing Tip Option for T&D Shaft Rockers $295
Timing
Cloyes 2 Piece Aluminum Timing CoverImage Close$195
Jesel "Original 2 pc" Belt Drive $1145
Oil Pumps - Oil Pans - Vacuum Pump
Moroso Kickout Style Pro Pan w/Solid Louvered Tray & Main Cap Partitions For Added Power & Oil Control. (Includes New Wing Design Oil Pump) $395
Additional Parts - Labor - Accessories
Boninfante Severe Duty SFI Flexplate & ARP Bolt PackageImage Close$229
Boninfante SFI Billet Flexplate & ARP Bolt PackageImage Close$395
PowerMaster Hi-Torque Mini StarterImage Close$229
Meziere 55GPH Electric Water PumpImage Close$535
SSRE Engraved Sheet Metal Valve CoversImage Close$375
